Rafale Safran's contribution to the Rafale (Dassault aviation)

Click on points to see more Click on points to see more
Rafale M88 Engines Auxiliary Power Unit Inertial navigation system Landing and braking systems Wiring AASM Hammer System Power Transmission System Engine Controls Ejection Seat Cockpit Equipment Fuel management system Oxygen and pilot protection equipment
  • M88 Engines
    M88 Engines M88 Engines M88 Engines

    Dassault's Rafale fighter jet is powered by two M88 engines. This turbofan bypass engine is designed, developed and produced by Safran (Safran Aircraft Engines). It delivers 7.5 tons of thrust with afterburner.

    Photo : © Philippe Stroppa / Safran

    Learn more
  • Auxiliary Power Unit
    Auxiliary Power Unit Auxiliary Power Unit

    The Rubis 3 auxiliary power unit (APU) was designed by Safran (Safran Power Units) to meet the on-board power requirements of Dassault Aviation's Rafale fighter jet, powered by M88 engines made by Safran Aircraft Engines.

    Learn more
  • Inertial navigation system
    Inertial navigation system Inertial navigation system

    Safran (Safran Electronics & Defense) is one of the only actors in the sector to comprehensively master these related technologies, in the military field in particular: gyroscopes, rate gyros, accelerometers, embedded GPS receivers, electronics, navigation data processing, etc.

    Learn more
  • Landing and braking systems
    Landing and braking systems Landing and braking systems

    A world leader in landing and braking systems for military aircraft, Safran (Safran Landing Systems) supplies nose and main landing gear, wheels and carbon brakes, and all landing, steering, extension and retraction systems on the Rafale landing gear.

    Learn more
  • Wiring
    Wiring Wiring

    As its expertise covers the entire electrical chain of aircraft, Safran (Safran Electrical & Power) supplies 100% of the cabling on Dassault's Rafale fighter jet.

    Learn more
  • Système AASM Hammer
    AASM Hammer System AASM Hammer System AASM Hammer System
    (Modular Air-Ground Weapon)

    Safran (Safran Electronics & Defense) has developed a family of high-precision guided air-to-ground weapons. Consisting of several types of guidance kits and a range augmentation kit, the AASM has a salvo capacity, with multi-target processing, by day and by night and in all weather conditions.

    This equipment is optional on this program.
    Photo : © Alexandre Paringaux / Safran

    Learn more
  • Power Transmission System
    Power Transmission System Power Transmission System

    Safran (Safran Transmission Systems) provides the power transmission system for the M88 engine of the Rafale fighter jet. It enables the engine to completely reduce power and then boost back to full combat power in less than three seconds.

    Learn more
  • Engine Controls
    Engine ControlsEngine Controls

    Full-Authority Digital Electronic Control (FADEC) systems are developed by Safran (Safran Electronics & Defense). Specially developed for the Rafale, the FADEC is adapted to the specific design of the fighter aircraft engine and its use.

    Learn more
  • Filters
    Filters Filters (water, air, oils)

    Safran (Safran Filtration Systems) supplies the entire filtration system on the Rafale fighter jet: air filters, fuel filters and lubricants.

    Learn more
  • Ejection Seat
    Ejection Seat Ejection Seats

    The ejection seats equipping the Rafale are manufactured and supplied by Safran Martin-Baker France, a joint venture between Safran and Martin-Baker. When activated, they eject at a speed of approximately 15 m/s.

    Learn more
  • Cockpit Equipment
    Cockpit Equipment Cockpit Equipment

    The flight deck of Dassault’s Rafale fighter aircraft comprises several cockpit systems produced by Safran (Safran Electronics & Defense).

    Learn more
  • Fuel management system
    Fuel management system Fuel management system

    The Rafale fighter jet is equipped with a fuel gauging management and distribution system designed and produced by Safran (Safran Aerosystems), including aerial refueling pod.

    Learn more
  • Power distribution
    Power distribution Power distribution

    Electrical power distribution management systems on the Rafale military aircraft supplied by Safran (Safran Electronics & Defense) ensure an optimum electrical power supply with a very high reliability. Safran also supplies electrical generation and conversion equipement.

    Learn more
  • Oxygen and pilot protection equipment
    Oxygen and pilot protection equipment Oxygen and pilot protection equipment

    Safran (Safran Aerosystems) supplies anti G suits, combat flight jackets and single man rafts, as well as oxgyen generation and regulation systems.

    Learn more
